Onboarding Step by Step Process

These steps outline the process to onboard a customer to Surescripts Data Solutions, from account setup through data downloads.

ăndarăt

Note: This is Early Adopter documentation. Requirements and content are subject to change.

Step 1: Verify Access to Data Package Builder in Workbench

For instructions on how to set up access, see the Setting Up Access to Workbench & Data Package BuilderSetting Up Access to Workbench & Data Package Builder instructions.

Step 2: Generate Keys

Step 2a: Generate RSA Key Pairs for Data Package Builder Authentication

To authenticate with the Data Package Builder API, you need to generate a 2048-bit RSA key pair and upload the public key through the Client Keys interface.

Option 1: Using Open SSL (Recommended - Works on Linux, macOS, Windows)

Generate a 2048-bit RSA private key.

openssl genrsa -out private_key.pem 2048

Extract the public key.

openssl req -new -x509 -key privatekey.pem -out publickey509.pem -subj '/CN=data-package-builder'

Verify your keys pairs.

# View the private key
cat privatekey.pem
# View the public key
cat publickey509.pem

Option 2: Using PowerShell (Windows)

Generate RSA key pair.

$rsa = [System.Security.Cryptography.RSA]::Create(2048)

Export public key in X.509 SubjectPublicKeyInfo format.

$publicKey = $rsa.ExportSubjectPublicKeyInfo()
$publicPem = "-----BEGIN PUBLIC KEY-----`n" +
             [Convert]::ToBase64String($publicKey, 'InsertLineBreaks') +
             "`n-----END PUBLIC KEY-----"
$publicPem | Out-File -FilePath "public_key.pem" -Encoding ASCII

Export private key.

$privateKey = $rsa.ExportRSAPrivateKey()
$privatePem = "-----BEGIN RSA PRIVATE KEY-----`n" +
              [Convert]::ToBase64String($privateKey, 'InsertLineBreaks') +
              "`n-----END RSA PRIVATE KEY-----"
$privatePem | Out-File -FilePath "private_key.pem" -Encoding ASCII

Write-Host "Keys generated successfully!"
Write-Host "Public key is in X.509 SubjectPublicKeyInfo format"

What You'll Get:

After generation of the key pair, you will have two files:

private_key.pem - Your private key - CRITICAL: Keep this secure - Store it in a secure location (HSM, key vault, encrypted storage) - This will be used to sign a compact JWT to request an acess token from the authorization server

public_key.pem - Your public key - This is what you upload to Data Package Builder - Safe to share (it's called "public" for a reason) - Example format: -----BEGIN PUBLIC KEY----- MIIBIjANBgkqhkiG9w0BAQEFAAOCAQ8AMIIBCgKCAQEA0Z3VS5JJcds3... -----END PUBLIC KEY-----

Step 2b: Upload your Public Key

Navigate to Client Keys.

Paste the entire contents of public_key.pem (including the BEGIN/END lines).

Click Create Client.

Note: This will create the Client_ID that the customer will later use in Build the Compact JWT AssertionBuild the Compact JWT Assertion section.

⚠️ Important: Once you have created your Client ID, notify your Surescripts point of contact. Surescripts must configure your data package before you can proceed to the next steps.

You will not be able to continue until this configuration is complete.

Security Best Practices:

✅ DO:

Generate keys in a secure environment

Store private keys in a key vault or HSM for production use

Use strong file permissions on private key files (chmod 600 private_key.pem on Unix)

Rotate keys periodically

❌ DON'T:

Share or commit private keys to version control

Email private keys

Store private keys in plaintext in application code

Reuse the same key pair across multiple clients/applications

Step 2c: Common errors

The below table includes information on common errors that can be encountered when creating key pairs.

Error	Troubleshooting Information
"Invalid certificate/public key format" error	Ensure you're uploading the PUBLIC key, not the private key Verify the PEM headers are included Check for extra whitespace or line breaks
Key appears to upload but authentication fails	Verify the corresponding private key is being used for signing requests Ensure the key is either 2048 or 4096 (1024 is not allowed and larger key sizes will not fit in our 8 KB JWT input limit)

Step 3: Query Builder

The Query Builder in Workbench helps you create an OData query URL that defines exactly which prescribed medication data you want to retrieve from the Data Solutions API. You can build a query visually or edit it directly, depending on your preference.

Note: The Query Builder is optional; experienced users may submit manual OData queries directly.

OData is not the only type of request that is supported. For additional information on other uses for the Query Builder, see Query Builder OverviewQuery Builder Overview .

For additional information on OData, see https://learn.microsoft.com/en-us/odata/overview

Important: Before you begin:

You must be able to sign in to Workbench.

Your user must have access to Data Package Builder with the Query Edit role.

You must be working with the Prescribed Medication product in Data Solutions.

For instructions on this, see Setting Up Access to Workbench & Data Package BuilderSetting Up Access to Workbench & Data Package Builder.

Step 3a: Run the Query Builder (OData)

Select Query Builder.

Choose the Prescribed Medication product.

Select the columns you want returned (these map to $select in OData).

Add filters to limit results.

A PARTITION_DAY filter is required.

Select Generate from Selections to automatically build the OData query (or manually edit the query if you’re familiar with OData).

Copy the generated OData query URL.

Use the URL in your Data Solutions API GET request to retrieve Prescribed Medication data.

Note: For information on how to run the Query Builder for other use cases, see Key Steps (Applies to All Use Cases)Key Steps (Applies to All Use Cases)

Step 4: Determining PARTITION_DAY Filter

To determine which PARTITION_DAY filter to request, see the How to Use the EndpointsHow to Use the Endpoints page.

Step 5: Send REST Requests to Data Solutions API

Authentication

Learn how to authenticate with the Data Solutions API using OAuth 2.0 Client Credentials Grant with JWT Bearer Assertion.

What You'll Do

The Data Solutions API uses a two-step authentication process:

Build a JWT assertion - Create and sign a JWT claim using your ClientID and private key

Request an access token - Exchange the JWT assertion for an OAuth access token at the auth-server's /connect/token endpoint

Use the access token - Include the access token in API requests

┌─────────────┐                                ┌─────────────┐
│   Client    │                                │ Auth Server │
└──────┬──────┘                                └──────┬──────┘
       │                                              │
       │ 1. Build JWT assertion                       │
       │    (signed with private key)                 │
       │                                              │
       │ 2. POST /connect/token                       │
       │    (client_assertion = JWT)                  │
       ├─────────────────────────────────────────────>│
       │                                              │
       │ 3. Access token response                     │
       │<─────────────────────────────────────────────┤
       │                                              │
       │                                              │
       │                           ┌──────────────────┴─────┐
       │                           │ Data Solutions API     │
       │                           └──────────────────┬─────┘
       │                                              │
       │ 4. API request with access token             │
       ├─────────────────────────────────────────────>│
       │                                              │
       │ 5. Data response                             │
       │<─────────────────────────────────────────────┤
       │                                              │

Before You Begin

Make sure you have:

Client ID - A unique identifier for your application.

Private Key - An RSA private key in PKCS#8 PEM format.

Public Key Registration - Your public key must be registered with the auth server for your Client ID.

Private Key Format

Your private key must be in PKCS#8 PEM format:

-----BEGIN PRIVATE KEY-----
MIIEvgIBADANBgkqhkiG9w0BAQEFAASCBKgwggSkAgEAAoIBAQC...
... base64 encoded key data ...
-----END PRIVATE KEY-----

Step 5a: Build the Compact JWT Assertion

Create a JWT with the following structure, signed with your private key using the RS384 algorithm (RSASSA-PKCS1-v1_5 with SHA-384). This JWT proves your identity to the auth server.

JWT Header

{
  "alg": "RS384",
  "typ": "JWT"
}

JWT Payload

{
  "iss": "your-client-id",                                    // Issuer: your client ID
  "sub": "your-client-id",                                    // Subject: your client ID
  "aud": "ENVIRONMENT_AUTH_URL/connect/token",                // Audience: token endpoint URL
  "jti": "550e8400-e29b-41d4-a716-446655440000",              // JWT ID: unique identifier (UUID)
  "iat": 1706572800,                                          // Issued at: current Unix timestamp
  "nbf": 1706572800,                                          // Not before: current Unix timestamp
  "exp": 1706573100                                           // Expires: current timestamp + 5 minutes
}

Important field notes:

iss and sub must both be your Client ID

aud must be the exact token endpoint URL (including /connect/token)

jti must be unique for each request (use a UUID)

exp should be 5 minutes from iat (recommended maximum)

Example: Building JWT in Python

import jwt
import uuid
import time
from datetime import datetime, timedelta

# Your credentials
client_id = "your-client-id"
private_key = """-----BEGIN PRIVATE KEY-----
MIIEvgIBADANBgkqhkiG9w0BAQEFAASCBKgwggSkAgEAAoIBAQC...
-----END PRIVATE KEY-----"""
token_endpoint = "ENVIRONMENT_AUTH_URL/connect/token"

# Build the JWT payload
now = int(time.time())
payload = {
    "iss": client_id,
    "sub": client_id,
    "aud": token_endpoint,
    "jti": str(uuid.uuid4()),
    "iat": now,
    "nbf": now,
    "exp": now + 300  # 5 minutes from now
}

# Sign the JWT with RS384
client_assertion = jwt.encode(
    payload,
    private_key,
    algorithm="RS384"
)

print(f"JWT Assertion: {client_assertion}")

Example: Building JWT in C#

using System.IdentityModel.Tokens.Jwt;
using System.Security.Claims;
using System.Security.Cryptography;
using Microsoft.IdentityModel.Tokens;

// Your credentials
var clientId = "your-client-id";
var privateKeyPem = @"-----BEGIN PRIVATE KEY-----
MIIEvgIBADANBgkqhkiG9w0BAQEFAASCBKgwggSkAgEAAoIBAQC...
-----END PRIVATE KEY-----";
var tokenEndpoint = "ENVIRONMENT_AUTH_URL/connect/token";

// Load the private key
using var rsa = RSA.Create();
rsa.ImportFromPem(privateKeyPem);
var signingCredentials = new SigningCredentials(
    new RsaSecurityKey(rsa),
    SecurityAlgorithms.RsaSha384
);

// Build the JWT
var now = DateTime.UtcNow;
var handler = new JwtSecurityTokenHandler();
var token = handler.CreateJwtSecurityToken(
    issuer: clientId,
    audience: tokenEndpoint,
    subject: new ClaimsIdentity(new[] { new Claim("sub", clientId) }),
    notBefore: now,
    expires: now.AddMinutes(5),
    issuedAt: now,
    signingCredentials: signingCredentials
);

// Add the jti claim
token.Payload["jti"] = Guid.NewGuid().ToString();

var clientAssertion = handler.WriteToken(token);
Console.WriteLine($"JWT Assertion: {clientAssertion}");

Example: Building JWT in JavaScript/Node.js

const jwt = require('jsonwebtoken');
const { v4: uuidv4 } = require('uuid');
const fs = require('fs');

// Your credentials
const clientId = 'your-client-id';
const privateKey = fs.readFileSync('private_key.pem', 'utf8');
const tokenEndpoint = 'ENVIRONMENT_AUTH_URL/connect/token';

// Build the JWT payload
const now = Math.floor(Date.now() / 1000);
const payload = {
  iss: clientId,
  sub: clientId,
  aud: tokenEndpoint,
  jti: uuidv4(),
  iat: now,
  nbf: now,
  exp: now + 300 // 5 minutes
};

// Sign the JWT with RS384
const clientAssertion = jwt.sign(payload, privateKey, {
  algorithm: 'RS384'
});

console.log(`JWT Assertion: ${clientAssertion}`);

Step 5b: Request Access Token

Send a POST request to the auth server's /connect/token endpoint with the JWT assertion.

Request Format

POST /connect/token HTTP/1.1
Host: ENVIRONMENT_AUTH_URL
Content-Type: application/x-www-form-urlencoded

grant_type=client_credentials
&client_id=your-client-id
&client_assertion_type=urn:ietf:params:oauth:client-assertion-type:jwt-bearer
&client_assertion=<your-signed-jwt>
&scope=DsaApi

Parameters:

grant_type - Must be client_credentials

client_id - Your client identifier

client_assertion_type - Must be urn:ietf:params:oauth:client-assertion-type:jwt-bearer

client_assertion - The signed JWT from Step 1

scope - Must be DsaApi to access the Data Solutions API

Example: Request Token in Python

import requests

# Build the token request
token_url = "ENVIRONMENT_AUTH_URL/connect/token"
data = {
    "grant_type": "client_credentials",
    "client_id": client_id,
    "client_assertion_type": "urn:ietf:params:oauth:client-assertion-type:jwt-bearer",
    "client_assertion": client_assertion,
    "scope": "DsaApi"
}

# Request the access token
response = requests.post(token_url, data=data)
response.raise_for_status()

token_response = response.json()
access_token = token_response["access_token"]
expires_in = token_response["expires_in"]

print(f"Access Token: {access_token}")
print(f"Expires in: {expires_in} seconds")

Example: Request Token in C#

using System.Net.Http;

var httpClient = new HttpClient();
var tokenUrl = "ENVIRONMENT_AUTH_URL/connect/token";

var requestData = new Dictionary<string, string>
{
    { "grant_type", "client_credentials" },
    { "client_id", clientId },
    { "client_assertion_type", "urn:ietf:params:oauth:client-assertion-type:jwt-bearer" },
    { "client_assertion", clientAssertion },
    { "scope", "DsaApi" }
};

var response = await httpClient.PostAsync(tokenUrl, new FormUrlEncodedContent(requestData));
response.EnsureSuccessStatusCode();

var tokenResponse = await response.Content.ReadFromJsonAsync<TokenResponse>();
var accessToken = tokenResponse.AccessToken;
var expiresIn = tokenResponse.ExpiresIn;

Console.WriteLine($"Access Token: {accessToken}");
Console.WriteLine($"Expires in: {expiresIn} seconds");

// Token response model
public class TokenResponse
{
    [JsonPropertyName("access_token")]
    public string AccessToken { get; set; }

    [JsonPropertyName("expires_in")]
    public int ExpiresIn { get; set; }

    [JsonPropertyName("token_type")]
    public string TokenType { get; set; }
}

Example: Request Token in JavaScript/Node.js

const axios = require('axios');
const qs = require('querystring');

const tokenUrl = 'ENVIRONMENT_AUTH_URL/connect/token';

const requestData = {
  grant_type: 'client_credentials',
  client_id: clientId,
  client_assertion_type: 'urn:ietf:params:oauth:client-assertion-type:jwt-bearer',
  client_assertion: clientAssertion,
  scope: 'DsaApi'
};

axios.post(tokenUrl, qs.stringify(requestData), {
  headers: { 'Content-Type': 'application/x-www-form-urlencoded' }
})
.then(response => {
  const accessToken = response.data.access_token;
  const expiresIn = response.data.expires_in;

  console.log(`Access Token: ${accessToken}`);
  console.log(`Expires in: ${expiresIn} seconds`);
})
.catch(error => {
  console.error('Token request failed:', error.response?.data || error.message);
});

Successful Response

{
  "access_token": "eyJhbGciOiJSUzM4NCIsImtpZCI6IjEyMzQ1Njc4OTAiLCJ0eXAiOiJKV1QifQ...",
  "expires_in": 3600,
  "token_type": "Bearer",
  "scope": "DsaApi"
}

Error Response

{
  "error": "invalid_client",
  "error_description": "Invalid client or client credentials"
}

Common error codes:

invalid_client - Client ID not found or public key mismatch

invalid_grant - JWT assertion validation failed

invalid_scope - Requested scope not available

Step 5c: Use Access Token in Data Solutions API Requests

Include the access token in the Authorization header of your API requests.

Request Format

GET /api/v0/odata/PrescribedMedicationData?$filter=PARTITION_DAY eq '2025-01-30' HTTP/1.1
Host: ENVIRONMENT_DATA_SOLUTIONS_URL
Authorization: Bearer <your-access-token>

Example: API Request in Python

import requests

api_url = "ENVIRONMENT_DATA_SOLUTIONS_URL/api/v0/odata/PrescribedMedicationData"
headers = {
    "Authorization": f"Bearer {access_token}"
}
params = {
    "$filter": "PARTITION_DAY eq '2025-01-30'",
    "$top": 10
}

response = requests.get(api_url, headers=headers, params=params)
response.raise_for_status()

data = response.json()
print(f"Retrieved {len(data['value'])} records")

Example: API Request in C#

var apiUrl = "ENVIRONMENT_DATA_SOLUTIONS_URL/api/v0/odata/PrescribedMedicationData";
var httpClient = new HttpClient();
httpClient.DefaultRequestHeaders.Authorization =
    new AuthenticationHeaderValue("Bearer", accessToken);

var queryParams = new Dictionary<string, string>
{
    { "$filter", "PARTITION_DAY eq '2025-01-30'" },
    { "$top", "10" }
};

var queryString = string.Join("&", queryParams.Select(kvp =>
    $"{Uri.EscapeDataString(kvp.Key)}={Uri.EscapeDataString(kvp.Value)}"));
var requestUrl = $"{apiUrl}?{queryString}";

var response = await httpClient.GetAsync(requestUrl);
response.EnsureSuccessStatusCode();

var data = await response.Content.ReadFromJsonAsync<ODataResponse>();
Console.WriteLine($"Retrieved {data.Value.Count} records");

Example: API Request in JavaScript/Node.js

const axios = require('axios');

const apiUrl = 'ENVIRONMENT_DATA_SOLUTIONS_URL/api/v0/odata/PrescribedMedicationData';
const headers = {
  'Authorization': `Bearer ${accessToken}`
};
const params = {
  '$filter': "PARTITION_DAY eq '2025-01-30'",
  '$top': 10
};

axios.get(apiUrl, { headers, params })
  .then(response => {
    console.log(`Retrieved ${response.data.value.length} records`);
  })
  .catch(error => {
    console.error('API request failed:', error.response?.data || error.message);
  });

Step 5d: Handle Token Expiration

Access tokens expire after the time specified in the expires_in field (typically 3600 seconds / 1 hour).

Best practices:

Store the token and its expiration time

Check if the token is expired before each request

Request a new token when the current one expires or is about to expire

Add a buffer (e.g., refresh 5 minutes before actual expiration)

Example: Token Management in Python

from datetime import datetime, timedelta

class TokenManager:
    def __init__(self, client_id, private_key, token_endpoint):
        self.client_id = client_id
        self.private_key = private_key
        self.token_endpoint = token_endpoint
        self.access_token = None
        self.expires_at = None

    def get_access_token(self):
        # Return cached token if still valid
        if self.access_token and datetime.utcnow() < self.expires_at:
            return self.access_token

        # Request new token
        client_assertion = self._build_jwt()
        response = requests.post(self.token_endpoint, data={
            "grant_type": "client_credentials",
            "client_id": self.client_id,
            "client_assertion_type": "urn:ietf:params:oauth:client-assertion-type:jwt-bearer",
            "client_assertion": client_assertion,
            "scope": "DsaApi"
        })
        response.raise_for_status()

        token_response = response.json()
        self.access_token = token_response["access_token"]

        # Set expiration with 5-minute buffer
        expires_in = token_response["expires_in"]
        self.expires_at = datetime.utcnow() + timedelta(seconds=expires_in - 300)

        return self.access_token

    def _build_jwt(self):
        # JWT building logic from Step 1
        now = int(time.time())
        payload = {
            "iss": self.client_id,
            "sub": self.client_id,
            "aud": self.token_endpoint,
            "jti": str(uuid.uuid4()),
            "iat": now,
            "nbf": now,
            "exp": now + 300
        }
        return jwt.encode(payload, self.private_key, algorithm="RS384")

# Usage
token_manager = TokenManager(client_id, private_key, token_endpoint)
access_token = token_manager.get_access_token()

Optional: Use DPoP for Enhanced Security

The API supports DPoP (Demonstration of Proof-of-Possession) for enhanced security. DPoP binds access tokens to a specific key pair, preventing token theft.

DPoP Token Request

Include a DPoP proof JWT in the DPoP header:

POST /connect/token HTTP/1.1
Host: auth-server.surescripts.net
Content-Type: application/x-www-form-urlencoded
DPoP: <dpop-proof-jwt>

grant_type=client_credentials
&client_id=your-client-id
&client_assertion_type=urn:ietf:params:oauth:client-assertion-type:jwt-bearer
&client_assertion=<your-signed-jwt>
&scope=DsaApi
&dpop_jkt=<jwk-thumbprint>

DPoP Proof Structure

Header:

{
  "typ": "dpop+jwt",
  "alg": "RS256",
  "jwk": {
    "kty": "RSA",
    "n": "<base64url-modulus>",
    "e": "<base64url-exponent>"
  }
}

Payload:

{
  "htu": "ENVIRONMENT_AUTH_URL/connect/token",
  "htm": "POST",
  "iat": 1706572800,
  "jti": "unique-id-here"
}

DPoP API Request

When using a DPoP-bound token, include the DPoP proof in API requests:

GET /api/v0/odata/PrescribedMedicationData HTTP/1.1
Host: ENVIRONMENT_DATA_SOLUTIONS_URL
Authorization: DPoP <access-token>
DPoP: <dpop-proof-jwt>

The DPoP proof for resource requests must include the ath claim (access token hash):

{
  "htu": "ENVIRONMENT_DATA_SOLUTIONS_URL/api/v0/odata/PrescribedMedicationData",
  "htm": "GET",
  "iat": 1706572800,
  "jti": "unique-id-here",
  "ath": "<base64url-sha256-of-access-token>"
}

For detailed DPoP implementation, see the Postman Collection README.

Troubleshooting

"invalid_client" Error

Cause: Client ID not found or public key mismatch

Solutions:

Verify your Client ID is correct

Ensure your public key is registered with the auth server

Confirm the private key matches the registered public key

"invalid_grant" Error

Cause: JWT assertion validation failed

Solutions:

Check JWT expiration (exp claim) - ensure it's in the future

Verify aud claim matches the exact token endpoint URL

Ensure iss and sub both contain your Client ID

Confirm JWT is signed with RS384 algorithm

Check that JWT jti is unique

401 Unauthorized on API Requests

Cause: Invalid or expired access token

Solutions:

Verify the token hasn't expired

Check that you're using Bearer token type

Ensure the token was requested with scope=DsaApi

Confirm the Authorization header format: Bearer <token>

403 Forbidden on API Requests

Cause: Valid token but insufficient permissions

Solutions:

Verify your client has purchased the product/package

Check if the columns you're selecting are in your package

Ensure you're including a valid PARTITION_DAY filter

Review package filter restrictions

Token Request Timeout

Cause: Network connectivity or server issues

Solutions:

Check network connectivity to the auth server

Verify the auth server URL is correct

Check firewall rules allow outbound HTTPS

Environment URLs

Environment	Auth Server URL	Data Solutions API URL
Production	https://auth-server.surescripts.net	https://data-solutions-api.surescripts.net

Security Best Practices

Protect Private Keys

Never commit private keys to source control

Store keys securely (e.g., environment variables, key vaults)

Use different keys for different environments

Token Storage

Store tokens securely in memory or encrypted storage

Never log or expose tokens in error messages

Clear tokens when they expire

JWT Claims

Always use unique jti values (UUIDs)

Keep expiration times short (5 minutes recommended)

Validate token expiration before use

HTTPS Only

Always use HTTPS for token requests and API calls

Verify SSL/TLS certificates

Error Handling

Implement retry logic for transient failures

Log authentication failures for monitoring

Don't expose sensitive details in client-facing errors

Step 6: Download Data Files (Optional Formats)

The Data Solutions API supports optional file download formats that may be enabled for your data package. Available formats depend on your package configuration.

Supported Formats

CSV – Human‑readable format for simple downloads and manual review

Parquet – Binary, columnar format optimized for analytics and large‑scale processing

Note: File format availability is controlled at the package level by Surescripts. If a format is not enabled for your package, it is not available for download.

Before You Begin

Confirm that:

Your Client ID is configured with a package that supports the desired file format

You have completed authentication in Step 5

You have a valid PARTITION_DAY value

File format selection does not affect query construction or authentication.

Download CSV Data (For Enabled CSV Packages Only)

Send a request to the following endpoint to download CSV data using a signed URL. The signed URL is active for 5 minutes and is only available is you are enabled for CSV downloads.

Prescribed Medication Data:

/api/v0/customer/product/PrescribedMedicationData/csv/signedurls/{PARTITION_DAY}

Download Parquet Data (For Enabled Parquet Packages Only)

Send a request to the following endpoint to download Parquet data using a signed URL. The signed URL is active for 5 minutes and is only available is you are enabled for Parquet downloads.

Prescribed Medication Data:

/api/v0/customer/product/PrescribedMedicationData/parquet/signedurls/{PARTITION_DAY}
